ALTRONIC EZRAIL JUNCTION BOX MODULE 593500-202

The Altronic EZRail system provides operators of natural gas
engines with a factory-built and tested ignition wiring and coil
mounting solution for use in conjunction with almost any Altronic
ignition system. These systems eliminate costly, custom on-site
ignition wiring header fabrication and the reliability and long-term
service and maintenance issues associated with them.
Where required, they also provide a convenient, well-supported
means of mounting the system ignition coils. In the same way
that the ignition system, harnesses, coils, and spark plugs are
purchased by part number, an engine-specific ignition rail
header can now be purchased from Altronic by part number.
With extended, trouble-free service as the design and manufacturing goal, premium materials are used in the construction. Anodized aluminum extrusions, stainless-steel hardware, militarystyle potted connectors, and strain-relieved wiring assemblies
are a standard part of each EZRail system. Many EZRail systems
also include a unique, sealed junction box that offers access to
the #1 ignition coil primary and the system shutdown lead. The
connectorized nature of the system allows for quick removal in
the event that on-engine mechanical service work is required.
Most Altronic ignition systems are supported by the EZRail
system. EZRail systems are designed to be used with either
shielded or unshielded primary and secondary cables, and
with any Altronic ignition
coil. The ignition coils
can be attached to the
wiring rail using an optional bolt-on coil rail to
the back of the wiring rail
itself or mounted directly
to the engine.
